CAD Services

VERTICALONION is a company built by engineers. Alongside our manufacturing capability, we have in house CAD expertise with a history in industries such as automotive, defence, marine, nuclear and Formula 1.
We know what it takes to successfully Design for Additive Manufacture (DfAM) and understand how manufactured parts will be incorporated in systems from our Design for Assembly (DfA) background.
This is knowledge we can share with our customers. We have the technology, and knowledge to support you to take your project from concept to reality.

To get a quote for your CAD requirement, click Get CAD Support.

Get CAD Support
CAD File Creation

Our experienced engineers convert your sketches, 2D technical drawings and 3D models into CAD files such as .stl .step .igs and .3mf.

Part Optimisation

We turn our clients unique and innovative designs into printable 3D models that bring their visions to life in the real world.

Three plastic jugs are shown on a black background
Three plastic jugs are shown on a black background
white and black electronic device
white and black electronic device
person in white shirt holding black and white smartphone
person in white shirt holding black and white smartphone
3D Scanning

From old part to printable replica, our 3D scanning service uses the latest technology and techniques to deliver exceptional results.

Available Services

Get a CAD Quote

Complete the below form and one of our engineers will contact you to discuss your requirements.
